Food Ink Jet Printer IJP Elfin IH

Food Ink Jet Printer IJP Elfin IH

Product Code: MACHEQ-F-M9801005

Categories: Bottle Filling and Batch Coding Machinery

Tags: Food Ink Jet Printer IJP Elfin IH


Download PDF Enquire Now
  • Description
  • Specification

Food Ink Jet Printer IJP Elfin IH

Color & Page    Single Color
Automation Grade    Semi-Automatic
USB Available    Yes
Condition    New

World''s Lightest Industrial Handheld Non-Contact Ink Jet Printer Model IJP – Elfin IH, which is a 4-in-1 Compact design, Zero Maintenance, 300 dpi high resolution, Battery Powered SIX line (character height 1 to 12.7 mm) Printer & can be used on Porous / Non-Porous products to print B.No., Exp.Date, Time, , Scannable Variable Bar Codes, etc. on labels, cartons, pouches, drums, containers, etc. It is fully programmable using the 5 inch full colour Touch Screen LCD with stand-alone operation (no PC required) where it can print 6 lines Data & all Computer Fonts (local languages) at a very low price.

Display 5” full color Touch Screen LCD with LED backlight.
Languages English, Spanish, French, German, Chinese, etc.
Input Device 800 x 480 Touch Screen LCD.
Printable Images Alphanumeric, Logo, Date/Time, Counter, Barcode, etc. UPCA, UPCE, EAN13, EAN8, INT25, CODE39, CODE128, ENA128, PDF417, DATAMATRIX, QR; (Allows user to add the barcode)
Printing Area 1 to 6 lines of 120 char. each from 1 to 12.7 mm high.
Message Capacity Store upto 999 messages with Message Name.
Printing Speed Max. 60 meters/min for 1 to 4 line printing at 300 dpi
Prints Using Hewlett-Packard (hp) TIJ 2.5 Print-head for spraying ink
Print Distance Max. 6 mm from substrate down or in front.
Inking Medium 42 cc disposable pre-mix ink in Cartridge form with head.
Printing Medium Solvent/Oil based inks (black, red*, blue*, yellow*, etc.)
Ink Drying Time Min. 5 seconds on plastics & laminates.
Impressions Appx. 4 Million char. of 2 mm per cartridge of ink.
Operating Range 10 ~ +55ºC 10% - 85% RH, non-condensing.
Supply Voltage 90 - 240 Vac, 50/60 Hz, 600 W
Dimensions H144 x W123 x D236 mm
Weight 1.0 Kg excluding cartridge & battery.
