Food Industrial On-Line Non-Contact Large Character Ink Jet Printer

Food Industrial On-Line Non-Contact Large Character Ink Jet Printer

988

Download PDF Enquire Now
  • Description
  • Specification

Food Industrial On-Line Non-Contact Large Character Ink Jet Printer

Ink Type    Black
Model/Type    Automatic
Printing Method    Ink Jet
Automation Grade    Automatic
Color & Page    Single Color
Voltage    230 Vac
CE Certified    Yes
Certification    CE

Industrial On-Line Non-Contact Large Character Ink Jet Printer which is a Zero Maintenance, Mains Powered TWO line (character height 20 to 50 mm) Printer & can be used on Porous / Non-Porous products to print   etc. on labels, cartons, pouches, drums, containers, etc. It is an ultra-compact and light inkjet printer equipped with a print-head with electromagnetic valves. It has built in keyboard & display where it can print 2 lines Data & all Computer Fonts (local languages) at a very low price.

Display Graphic LCD display
Input Device QWERTY Keyboard
Printable Images Alphanumeric, Logo, Date/Time, Counter, etc.
Printing Area 1 to 2 lines of 150 char. each from 20 to 50 mm high.
Printing Matrix 5 × 5, 5 × 7, 10 × 10, 10 × 16, 16 × 16
Message Capacity 16 memory location, 150 characters (5 × 7) per message, 75 characters (16 ×16) per message
Printing Speed Max. 91 meters/min for 1 to 2 line printing
Prints Using 16 Nozzle electromagnetic valve Print-head for spraying ink
Print Distance Max. 25 mm from substrate.
Inking Medium 150 cc ink in Cartridge form, 250 g ± 5 g
Printing Medium MEK / Solvent / Oil based inks (black, red*, blue*, white*, etc.)
Ink Drying Time Min. 10 seconds on plastics & laminates.
Impressions Appx. 4 million char. of 2 mm per cartridge of ink.
Operating Range 5 ~ +45ºC, 10% - 90% RH, non-condensing.
Supply Voltage 90 to 270 VAc
Dimensions 212 x 135 x 120 mm
Weight 1.1 Kg ± 10 g including full ink cartridge & battery.

The system is inclusive of below mentioned accessories worth Rs. 30,000/- free of cost:

a. Molded Box with molded slots for printer & accessories.

b. Computer Software.

c. 1 No. Pre-mix ink cartridge, 1 No. Solvent Cartridge.

d. Operator Tool Kit, Operation & Maintenance Manual, Instruction Video CD.
